Dirt jump DNA with all the speed and roll-over of 29" wheels. The San Quentin 3 29 is the top dog in the SQ 29 family. We’ve worked tirelessly to create the very best-specced San Quentin 29 ever but still kept the price tag down to earth and in reach of everyone. Marzocchi Z2 fork? Check. Tektro 4-piston brakes and 12-speed drivetrain? TranzX dropper post? You got it. FSA cranks, Maxxis rubber and plenty of kick-ass Marin kit? Abso-freakin-lutely.
Key upgrades over the San Quentin 2 29":
- Marzocchi Bomber Z2 fork
- Shimano Deore wide-range 12-speed drivetrain
- Tektro Slate EVO 4-piston brakes
- Maxxis Assegai tubeless compatible tires
-
FRAME
All New Series 3 6061 Aluminum, Double Butted, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
-
FRONT SUSPENSION
Marzocchi Bomber Z2, 110x15mm Boost Spacing, 140mm Travel, Kabolt Axle, 44mm Offset
-
RIM
Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Sleeved Joint, 32H, Tubeless Compatible
-
HUB REAR
Shimano FH-TC500, 148x12, MicroSpline Freehub Body, Centerlock Disc, 32H
-
HUB FRONT
Shimano HF-MT410B, 110x15mm, Disc
-
SPOKES NIPPLES
14g Black Stainless Steel
-
TIRES
Maxxis Assegai, 29 x 2.5" MAXX TERRA, EXO Casing, Tubeless Compatible
-
DERAILLEUR REAR
Shimano Deore, 12-Speed, SGS
-
DERAILLEUR FRONT
-
-
SHIFT LEVER
Shimano Deore, 12-Speed, SL-6100IR
-
CRANKSET
FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
-
BOTTOM BRACKET
FSA MegaExo 73mm BSA
-
CHAIN
KMC X-12 Silver and Black
-
CASSETTE
SunRace, 12-Speed, MicroSpline, 10-51T
-
BRAKES FRONT
TRP Slate EVO, 4-Piston Hydraulic, Resin Pads, 203mm Rotor
-
BRAKES REAR
TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 180mm Rotor
-
BRAKE LEVERS
TRP Slate EVO, I-Spec EV Compatible
-
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
-
STEM
Marin 3D Forged Alloy, 35mm
-
GRIPS
Marin Grizzly Lock On
-
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
-
SEATPOST
TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M 150mm Travel, Size L-XL 170mm Travel, 30.9mm
-
SADDLE
Marin Speed Concept
-
PEDALS
Marin Oso OE Flat
| SM | MD | LG | XL | |
| STACK | 632 | 636 | 645 | 650 |
| REACH | 422 | 450 | 470 | 500 |
| HEADTUBE ANGLE | 64° | 64° | 64° | 64° |
| HEADTUBE LENGTH | 115 | 120 | 125 | 130 |
| SEATTUBE ANGLE | 77° | 77° | 77° | 77° |
| SEATTUBE LENGTH | 330 | 380 | 410 | 420 |
| TOPTUBE EFFECTIVE | 568 | 596 | 619 | 650 |
| BB HEIGHT | 316 | 316 | 316 | 316 |
| BB DROP | 50 | 50 | 50 | 50 |
| CHAINSTAY | 430 | 430 | 430 | 430 |
| WHEELBASE | 1182 | 1212 | 1236 | 1268 |
| STANDOVER HEIGHT | 650 | 683 | 688 | 695 |
| FORK OFFSET | 44 | 44 | 44 | 44 |
| SEATPOST DIAMETER | 30.9 | 30.9 | 30.9 | 30.9 |
| HANDLEBAR WIDTH | 780 | 780 | 780 | 780 |
| STEM LENGTH | 35 | 35 | 35 | 35 |
| CRANK LENGTH | 170 | 170 | 170 | 170 |
