For the rider who dreams of endless singletrack, boosting jumps, and getting fitter and faster, meet your new bike, the Levo SL. The Levo SL delivers an unmatched lightweight ride quality and amplified capability. You’ll be blown away by its combination of flawless handling, capability, and “2X You” amplification that gives you the Power to Ride More Trails. Compare it to anything out there, with a motor or without, and we know you’ll agree—Levo SL is The Ultimate Trail Bike.
IT’S ALL ABOUT THE RIDE: When everything works just right, a bike disappears when you ride it. We stripped away the mass to keep the Levo SL lean and responsive. It’s tough enough to withstand heavy abuse but light enough to flick around and pick apart a rock garden. Its dialed geometry, kinematics, and shock tuning leave nothing desired.
THE MAGIC CARPET RIDE: GENIE is our patent-pending air spring technology that we invented that grants every trail rider’s three wishes: maximum grip and traction of a coil spring, better bottom-out prevention than a standard air spring, and the ability to tune mid-stroke and end-stroke support independently. GENIE combines the control-enhancing linear spring rate feel of a coil spring through the “bump zone” with the progressive spring rate of an air spring at the end of the stroke to avoid bottom-outs. Truly, it's the best of both worlds.
GEOMETRY OF CONTROL: Our design focuses on performance and control from start to finish. A strategic carbon fiber layup ensures a responsive, stiff chassis, minimizing lateral flex for efficient power transfer. The cockpit enhances traction and cornering precision with a low bottom bracket, slack headtube angle, and customizable head angle options (63°, 64.25°, 65.5°) for stability and agility through any terrain.
MIXED WHEEL: A 29” front wheel helps ensure stability and surefooted performance in the most hectic terrain, while a 27.5” rear wheel allows for a short chainstay and super responsive behavior. If you prefer the rolling and traction benefits of a 29” rear wheel, just flip the pivot link chip and mount the big wheel.
TURBO OPERATING SYSTEM: Our seamlessly integrated operating system delivers unmatched performance across torque, range, ride feel, ride quality, power, reliability, and rider experience. It’s the invisible hand that enables you to do more, know more, go farther, feel stronger, and have more fun.
SPECIALIZED SL 1.2 MOTOR: Meet the Specialized SL 1.2 motor: whisper-quiet with unmatched smoothness, it delivers 43% more torque (50Nm) and 33% more power (320 Watts) than its predecessor, unleashing "2x You" performance. Paired with a seamless 320Wh battery pack, the Levo SL ensures premium quality and supports rides for up to 5 hours in Eco Mode. Extend your journey with our 160Wh Range Extender (sold separately), fitting snugly into your bottle cage for an extra 50% range.
IT’S ALL CONNECTED: MasterMind TCU, our advanced e-bike control unit, seamlessly connects with Turbo OS and the Specialized App. Adjust power levels with MicroTune, live over-the-air updates for optimized performance, and more. The Levo SL integrates fully with the Specialized App, offering personalized motor settings and advanced security features like Smart Control and Turbo System Lock.
- GENIE | FOX FLOAT Performance Elite Shock - Specialized GENIE air spring technology inside, Ride Dynamics Tuned
- FOX FLOAT 36 Rhythm - A value forward fork with simple adjustability
- SRAM Maven Bronze - High-powered brakes with Centerline rotors featuring excellent heat dissipation
- SRAM AXS Drivetrain - SRAM Eagle wide range cassette and wireless derailleur
- X-Fusion Maniac - A simple and internally routed dropper post
- Wiring Harness
- Custom Specialized wiring harness
- Charger
- Custom charger, 48V System w/ SL system charger plug
- Motor
- Specialized 1.2 SL Custom Rx Trail Tuned Motor
- UI/Remote
- Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
- Battery
- Specialized SL1-320, fully integrated, 320Wh
- Stem
- Alloy Trail Stem, 35mm bar bore
- Saddle
- Bridge Comp, Hollow Cr-mo rails, 155/143mm
- Handlebars
- Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise
- Grips
- Specialized Trail Grips
- SeatPost
- X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4: 170mm, S5/S6: 190mm
- Seat Binder
- Alloy, 38.6mm
- Frame
- Levo SL Alloy Frame, M5 alloy, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels
- Fork
- FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
- Rear Shock
- FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm
- Front Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
- Rear Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
- Chainrings
- SRAM T-type ring, 32t
- Crankset
- SRAM S1000 Crankset, 32T ring, Integrated Guard, 55mm Chainline, 165mm
- Chain
- SRAM GX Eagle, 12-speed
- Shift Levers
- SRAM GX Eagle, trigger, 12-speed, single click
- Rear Derailleur
- Sram X01 Eagle, 12-speed
- Cassette
- Sram XG-1275, 12-speed, 10-52t
- Rear Hub
- Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
- Front Hub
- Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- Spokes
- DT Swiss Industry
- Rear Tire
- Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3"
- Rims
- Specialized 29/27.5, hookless alloy, 30mm inner width, tubeless ready
- Inner Tubes
- Standard, Presta Valve
- SWAT
- SWAT CC steerer tube integrated tool with chain tool and link
- Product ID
- 221303
- Weight
- 20.26 kg (44 lb, 10.7 oz)
- Weight Size
- S4
S1 | S2 | S3 | S4 | S5 | S6 | |
Crank Length | 165 | 165 | 165 | 165 | 165 | 165 |
Handlebar Width | 780 | 780 | 800 | 800 | 800 | 800 |
Stem Length | 40 | 40 | 40 | 40 | 40 | 40 |
Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
Seatpost Length | 100 | 125 | 150 | 170 | 170 | 190 |
Stack | 609 | 617 | 626 | 635 | 645 | 654 |
Reach | 405 | 425 | 445 | 470 | 495 | 525 |
Head-Tube Length | 95 | 100 | 110 | 120 | 130 | 140 |
Head-Tube Angle | 64.6 | 64.6 | 64.6 | 64.6 | 64.6 | 64.6 |
B-B Height | 343 | 348 | 348 | 348 | 348 | 348 |
B-B Drop | -34 | -29 | -29 | -29 | -29 | -29 |
Trail | 132 | 132 | 132 | 132 | 132 | 132 |
Fork Length, Full | 560 | 570 | 570 | 570 | 570 | 570 |
Fork Rake/Offset | 42 | 42 | 42 | 42 | 42 | 42 |
Front-Center | 726 | 752 | 776 | 806 | 835 | 869 |
Chain-Stay Length | 433 | 432 | 432 | 432 | 432 | 432 |
Wheelbase | 1158 | 1184 | 1208 | 1238 | 1267 | 1301 |
Top Tube Length, Horizontal | 560 | 582 | 604 | 631 | 659 | 691 |
Bike Stand-Over Height | 727 | 763 | 766 | 767 | 773 | 778 |
Seat-Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
Seat-Tube Angle | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 |
