The Mountain Bikers E Bike
Living in uncharted territory, the Relay is a lightweight, mid-power ebike here for all of your rides, battery or human powered. From square one the Relay was built with modularity in mind. Starting with a frame that accommodates 160 or 170 travel front and rear, as well as dual 29 or mixed wheels, this bike is ready for any trail you point it down. At the core of this chariot is the Fazua Ride 60 system that provides 60nm of power to get you up the hill, with a 430 wh battery to keep you going for miles on end. We have always wanted a bike that could provide both an ebike and a human powered experience in one chassis, and this is it. This system is light, efficient, and quiet, providing a more intuitive and natural feel on trail than many expect from a powered ride. The Relay is here to meet all of your mountain biking needs.
More images to come
Frame - Transition Relay Alloy
Motor - Fazua Ride 60
Battery - Fazua Energy 430 Removable
Display- Fazua LED Hub
Mode - Fazua Ring Ctrol
Rear Shock - Fox DHX Coil Factory Series
(170mm Travel/205x65)
Fork - Fox Float 38 Grip 2 Perfoprmance Elite 29
(170mm Travel/44mm Offset/1.5 Taper)
Headset - FSA No 55R/44
Stem - ANVL Swage (40mm)
Bar - ANVL Mandrel Alloy
(20mm XS/SM, 30mm MD/LG, 40mm XL)
Grips - ODI Elite Flow Lock-On
Sadde - SDG Bel-Air V3
Seatpost - OneUp Dropper Post
120mm XS
150mm SM
180mm MD
210mm LG/XL/XXL
Brakes - TRP DH-R EVO
Rotors - TRP R1 2.3 (203mm)
Shifter - SRAM GX
Derailleur - SRAM GX
Cassette - SRAM GX
Chain - SRAM GX
Crank - Praxis ETOR Alloy
(160mm XS, 165mm SM-XXL)
Chainring - SRAM 104 BCD 32t Alloy Ring
Spider - Transition Direct Mount Spider
Includes Bashguard
Rims - Raceface Aeffect R, 6069 Alloy
Spokes - RaceFace 2.0/1.7/2.0
J-Bend, w/Brass Nipples
Hubs - RaceFace Trace 28H
Front Tire - Schwalbe Magic Mary, Super Trail, Soft (29x2.4)
Rear Tire - Schwalbe Big Betty, Super Trail, Soft (27.5x2.4)
Other - Fazua Charger, Tubeless Valves & Sealant
| Geo | XS | XS PNW | SM | SM PNW | MD | MD PNW | L | L PNW | XL | XL PNW | XXL | XXLPNW |
| Reach | 410 | 405 | 430 | 422 | 460 | 452 | 485 | 477 | 510 | 502 | 535 | 527 |
| Stack (Carbon) | 590 | 588 | 615 | 615 | 628 | 634 | 637 | 643 | 646 | 652 | 655 | 661 |
| Stack (Alloy) | 595 | 593 | 620 | 620 | 628 | 634 | 637 | 643 | 646 | 652 | 655 | 661 |
| Effective TT Length | 523 | 532 | 553 | 564 | 586 | 597 | 614 | 631 | 642 | 665 | 671 | 696 |
| Seat Tube Length (Carbon) | 380 | 390 | 410 | 430 | 460 | 490 |
| Seat Tube Length (Alloy) | 410 | 410 | 410 | 430 | 460 | 490 |
| Effective ST Angle | 79.7 | 79.3 | 79.1 | 78.4 | 78.4 | 77.7 | 77.8 | 77.1 | 77.3 | 76.6 | 77.0 | 76.3 |
| Reference Seat Height | 560 | 600 | 660 | 720 | 780 | 820 |
| Actual ST Angle | 71 | 70.6 | 71 | 70.3 | 71 | 70.3 | 71 | 70.3 | 71 | 70.3 | 71 | 70.4 |
| ST Offset At BB | 90 | 90 | 90 | 90 | 90 | 90 |
| Head Tube Length (Carbon) | 100 | 100 | 115 | 125 | 135 | 145 |
| Head Tube Length (Alloy) | 105 | 105 | 115 | 125 | 135 | 145 |
| Head Tube Angle | 64.0 | 63.6 | 64.0 | 63.3 | 64.0 | 63.3 | 64.0 | 63.3 | 64.0 | 63.4 | 64.0 | 63.4 |
| Chainstay Length | 436 | 442 | 440 | 442 | 440 | 448 | 446 | 448 | 446 | 448 | 446 |
| Wheelbase | 1167 | 1172 | 1208 | 1211 | 1244 | 1247 | 1280 | 1282 | 1309 | 1312 | 1338 | 1341 |
| Bottom Bracket Drop | 15 | 11 | 25 | 25 | 25 | 25 | 25 |
| Estimated BB Height | 340 | 343 | 350 | 350 | 350 | 350 | 350 |
