The arc is back. Conjuring up all the nostalgia, hoots and hollars from yesteryear. It’s your instant-feedback steed for any trail. Show it your singletrack, pump track and your bikepack route too. It’s got history to live up to and new history to make. And it’s already impatient.
| Frameset | |
| Details | TURQ series carbon |
| Frame | TURQ series carbon fiber frame, Pressfit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, Universal derailleur hanger (UDH), and axle. |
| Fork | FOX FACTORY 34 FIT4/130MM |
| Material | TURQ SERIES |
| Weight | 2.96 |
| A | WHEEL SIZE | 29 | 29 | 29 | 29 |
| B | REACH | 16.5 | 17.5 | 18.3 | 19.3 |
| C | EFFECTIVE TOP TUBE LENGTH | 22.7 | 23.8 | 24.6 | 25.7 |
| D | Stack | 24.9 | 25.2 | 25.4 | 25.8 |
| E | HEADTUBE LENGTH | 3.7 | 4.1 | 4.3 | 4.7 |
| F | SEAT TUBE LENGTH | 15 | 16.1 | 17.7 | 19.5 |
| G | EFF. SEAT TUBE ANGLE | 76 | 76 | 76 | 76 |
| H | HEADTUBE ANGLE | 67 | 67 | 67 | 67 |
| I | ESTIMATED BB HEIGHT | 12.2 | 12.2 | 12.2 | 12.2 |
| J | CHAINSTAY LENGTH | 17.0 | 17.0 | 17.0 | 17.0 |
| K | FRONT CENTER | 28.0 | 29.1 | 30.0 | 31.1 |
| L | WHEELBASE | 45 | 46.1 | 47.0 | 48.2 |
| M | STANDOVER | 28.5 | 28.4 | 28.3 | 28.3 |
| N | AXLE TO CROWN | 21.4 | 21.4 | 21.4 | 21.4 |
| O | OFFSET | 1.7 | 1.7 | 1.7 | 1.7 |
| P | VERTICAL FORK TRAVEL | 4.7 | 4.7 | 4.7 | 4.7 |
