Dream big, without the big budget. The SILEX 200 is the entry to our world of adventure gravel riding, with our high-quality aluminium frame and lightweight carbon fork paired with affordable but durable components, such as a Shimano 2x9-speed Sora drivetrain and grippy, comfortable 45 mm Maxxis tyres. It’s the perfect weekday companion that turns into a willing partner in crime for big weekend bikepacking adventures.
The SILEX turns any ride into an adventure, whether you’re on a multi-day gravel bikepacking mission or just taking the fun route to work. With multiple test wins, press accolades, industry awards and even a World Championship title under its belt, our SILEX takes the off-road capability of gravel bikes to new heights, thanks to a slacker head angle and boosted tyre clearance of up to 700x45 mm or even 42 mm with fenders. We've combined that confident mountain bike-inspired handling with all-surface versatility so that it is utterly stable when loaded up with luggage but still fast and fun when you put the hammer down. With carbon and aluminium frame options, there's a SILEX to suit every budget, but they all share the multiple mounting points for fork cages, water bottles and accessories and other features that make this drop-bar do-everything machine so versatile. We’ve added our sleek WIRE PORT cable routing for improved looks – and fewer cables to catch on with a handlebar bag – and the carbon fibre fork used on all models now has more cargo mounts plus internal routing for a dynamo hub. With the ability to use 1x or 2x drivetrains, you can pick your gearing to suit the task at hand or your own personal preference, opening up a world of opportunity for you and your SILEX.
FRAME | SILEX LITE II; MAT aluminium; 700x47C max.WHS; 100x12/142x12 AST; BSA BBR |
SHOCK | |
FORK | MERIDA SILEX CF2 II; Tapered; MAT carbon; 700x47C max. WHS |
BRAKE-F | Promax DSK-330R; Mechanical disc |
BRAKE-R | Promax DSK-330R; Mechanical disc |
ROTOR-F | Promax 180V; 180mm |
ROTOR-R | Promax 160V; 160mm |
CHAIN | KMC M99 |
CHAINGUARD | |
CRANKSET | FSA Omega; 48-32 ATC |
CRANK LENGTH | 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL |
BOTTOM BRACKET | FSA MegaExo BB-4000 |
DERAILLEUR-FRONT | Shimano Sora |
DERAILLEUR-REAR | Shimano Sora; GS |
CASSETTE | Shimano CS-HG200; 11-34 ATC; 9 GER |
GRIPS | MERIDA ROAD Comp |
HANDLEBAR | MERIDA EXPERT GRII; MAT aluminium; 400mm (XS-S) , 420mm (M) , 440mm (L/XL) |
STEM | MERIDA COMP CC; 31.8 DSH; MAT aluminium; -7 ASD |
STEM SIZE | 80 mm all sizes |
HEADSET | 320.52.631 |
HUB-F | VP 173SB; 100x12 WHF; 32 SPH; 6 SBD |
HUB-R | VP 273SB; 142x12 WHR; 32 SPH; 6 SBD |
AXLE-F | MERIDA EXPERT TR |
AXLE-R | MERIDA EXPERT TR; including removable lever; 6/4mm allen key |
RIM | MERIDA COMP SL II; 23 IWR; 24 HRI; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
SADDLE | MERIDA COMP SL; 25% recycled material; V-mount |
SEAT CLAMP | MERIDA EXPERT |
SEATPOST | MERIDA COMP CC; MAT aluminium; 27.2 DSP; 5 SSB |
SHIFTER-FRONT | Shimano Sora |
SHIFTER-REAR | Shimano Sora |
SPOKES | Black stainless |
TIRE-F | Maxxis Rambler; 700x45C; fold; TR; EXO |
TIRE-R | Maxxis Rambler; 700x45C; fold; TR; EXO |
XS | SM | MD | LG | XL | |
Tyre Sizes | 700 | 700 | 700 | 700 | 700 |
ST seat tube [mm] | 440 | 470 | 500 | 530 | 560 |
TT top tube [mm] | 550 | 565 | 580 | 600 | 620 |
CS chain stay length [mm] | 430 | 430 | 430 | 430 | 430 |
HTA head tube angle [°] | 69.5 | 69.5 | 69.5 | 69.5 | 69.5 |
STA seat tube angle [°] | 74.5 | 74.5 | 74.5 | 74.5 | 74.5 |
BD bottom bracket drop [mm] | 75 | 75 | 75 | 75 | 75 |
HT head tube [mm] | 130 | 150 | 170 | 190 | 210 |
FL fork length [mm] | 415 | 415 | 415 | 415 | 415 |
R reach [mm] | 392 | 402 | 412 | 426 | 441 |
S stack [mm] | 570 | 588 | 607 | 626 | 645 |
WB wheel base [mm] | 1048 | 1065 | 1082 | 1104 | 1126 |
SH stand over height [mm] | 744 | 771 | 798 | 825 | 852 |
